| DIMENSION | ||
| T | 8 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 28 | Pinion O.D(mm) |
| ID | 12.5 | Pinion I.D.(mm) |
| L | 61 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 211445504 23312D0100 211415550 211425100 131986 54-8101 |
Nissan:Bluebird,Laurel,Prairiep,Stanza,Urvan,Z20 |
