| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 29.6 | Pinion O.D(mm) |
| ID | 12.5 | Pinion I.D.(mm) |
| L | 62 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 211455004 211465001 8942332270 8942332770 131085 54-8110 |
Honda:Accord 1600, 1599cc, Civic Isuzu:I Mark L4,Pick Up L4 Nissan:NFG101D11 Yanmar Engine Marine:1GM,2GMF,3GM |
