| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 29.5 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 49 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 1006209675 1006209607 F000AL1200 F000AL1250 F000AL1695 9947838 139954 224098 54-91113 |
Fiat:Brava,Marea, Toyota:Corolla,Fielder,Hilux |
